Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
1 / 5
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4

Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4

Send Inquiry

Product Description

RJ45 Modular Jack Banner
Through Hole Networking Plastic RJ45 Modular Jack
RJ45 Detail View

Technical Specifications

Tyco Part Number1116173-4
LINK-PP Part NumberLPJE101AHNL
Application-LANETHERNET (NON POE)
AutomDXYES
Package Height (Inches/mm)0.516/13.10
Package Length (Inches/mm)0.620/15.75
Package Width (Inches/mm)0.640/16.26
Configuration TX/RXT, C
Contact Mating Area PlatingGOLD 6u"/15u"/30u"
Cores Per Port-
DiodesNo
LatchUp
LED OptionGreen/Yellow LEDS
Number of Ports1X1
PCB Mount AngleSIDE ENTRY
PCB Retaining PostT POST
Pin TypeTHT SOLDER
RoHS CompliantYES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
SearchYES
Shield EMI TabsWITH
Speed-
Temperature-40 TO 85°C
Turns Ratio RX1CT:1
Turns Ratio TX1CT:1
