Transolix
1 / 5
| Item | Fiber Optical Modules |
| Part Status | Active |
| Form Factor | QSFP |
| Max Data Rate | 103.125Gbps (4x 25.78Gbps) |
| Max Cable Distance | 70m@OM3/100m@OM4 |
| Wavelength | 850nm |
| Connector | MTP/MPO-12 |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Transmitter Type | VCSEL 850nm |
| TX Power | -8.4~2.4dBm |
| Receiver Sensitivity | <-10.3dBm |
| Powerbudget | 1.9dB |
| Receiver Overload | 2.4dBm |
| Power Consumption | ≤2.5W |
| Extinction Ratio | >3dB |
| DDM/DOM | Supported |
| Warranty | 5 Years |
| Sample | Available |
| Protocols | IEEE 802.3bm, QSFP28 MSA, SFF-8665, SFF-8636, RoHS, CPRI, eCPRI |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Yes, we can offer you free samples to test quality, though the shipping fee needs to be covered by the customer.
Products in stock are ready to ship immediately, while standard mass production orders take 15 to 30 days.
We offer a one-year warranty period and provide 24-hour online technical support.
Yes, please send your project details or inquiries to us so we can proceed with a detailed discussion.
We possess over 19 years of dedicated production experience and work closely with leading partners across the industry to deliver reliable, high-performance networking solutions.
