| Part Number | LPJG47036AWNL |
| Application-LAN | ETHERNET(POE) |
| AutomDX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u"/50u" |
| Cores Per Port | 8 |
| Diodes | NO DIODES |
| LED Option | GREEN/GREEN |
| Latch | UP/DOWN |
| Number of Ports | 2X4 |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | WITH |
| Shielding | Shielded |
| Speed | 2.5G BASE-T |
| Temperature | -20~+70℃ |
| Turns Ratio RX | 1CT:1 |
| Turns Ratio TX | 1CT:1 |
The part number is LPJG47036AWNL, and it supports speeds up to 2.5G BASE-T.
Yes, it is designed for ETHERNET (POE) applications.
It features a 2x4 port layout configuration with 8 cores per port, utilizing a side-entry PCB mount angle and THT solder pin type.
The operating temperature range for this model is from -20℃ to +70℃.
Yes, the connector is fully shielded and comes equipped with EMI tabs for optimal signal integrity.
Yes, the connector is RoHS compliant (specifically RoHS-5 with lead in solder exemption).
